● Utilizes a unique optical component design for higher monochromaticity and better stray light suppression;
● Can be equipped with an electric filter wheel for easy and convenient operation;
● Offers a broader wavelength scanning range to meet the needs of photocatalysis and solar cell research across a wide wavelength spectrum.
▲ Particularly Suitable ● Moderately Suitable ○ Can Be Used
▲ Quantum Efficiency Measurement for Photocatalysis ▲ Solar Cell Testing
● Photoelectrochemical (PEC) ● Microfluidic Reactors ● Optical Absorption Testing
● Focal Length: 150 mm
● F-number (F/N): F/2.5
● Stray Light: 5×10-4
● Step Size Limit: 1 nm
● Grating Type: High-quality imported double gratings
● Grating Effective Area: 45×45 mm2
● Grating Groove Density: 2400 L (multiple specifications available)
● Grating Blaze Wavelength: 1#: 300 nm, 2#: 780 nm
● Wavelength Output Range: 350~750 nm
● Adjustable Slit Width: 0.01~3 nm continuously manually adjustable
● Filter Wheel (optional): Eliminates secondary diffraction, four-position electric filter wheel
